AMD Graphics Card Radeon RX 560





(3 stars by 328 users)


Radeon RX 560 is a graphics card from AMD, In terms of coloring, Radeon RX 560's shading ability is also good, because it has a stream processing unit number of 1024, and the stream processing unit is responsible for vertex shading and pixel shading, The number of 3.0 billion transistors gives it good performance while also bringing a lot of heat, The maximum power is 75 W (the higher the power, the greater the heat), The entire graphics card layout uses the GCN 4.0 architecture, 1271 MHz Boost frequency looks good and should be able to handle most games, It has a good single-precision floating-point computing power of 2.6 TFLOPS, In daily use, the GPU runs at around 1173 MHz, 123 mm² chip area has not changed much compared to the previous generation of graphics cards, Radeon RX 560 has only 4 GB GDDR5 video memory, but because of its good data processing speed, the actual working ability is still good, 14 nm's process technology means more transistors can be placed on a small chip, Speaking of the memory frequency, this graphics card is not very outstanding in this regard, only 1.7 Gbps, The graphics processor used by the GPU is Polaris 21, 128 bit bit of memory interface, allowing it to instantly through put data, The number of 3.0 billion transistors gives it good performance while also bringing a lot of heat, AMD has configured 64 texture unit numbers for it.

The Radeon RX 560 is built on Polaris 21, codenamed Baffin Pro, based on the fourth-generation GCN architecture. The Polaris 21 GPU has 16 CUs and 1024 cores instead of 14 CUs and 896 cores in the RX 460 / Polaris 11. In addition, the number of transistors and the die size remain the same, so the number of transistors is 3 billion and the chip size is 232 square millimeters. It is equipped with an 80W TDP, 128-bit memory bus and 1090 MHz base, 1287 MHz enhancement.

All Radeon RX 500 series support Radeon Chill, a game-based adaptive energy saving feature. Radeon ReLive can be used to capture, transmit and share your most exciting moments, AMD FreeSync technology, HEVC 4K decoding and AMD Eyefinity technology.



Radeon Chill Technology Introduction

AMD has released the Radeon Software Crimson ReLive Edition that brings a whole new set of features to players - Radeon Chill, which can be said to be "an energy-saving means beyond imagination". Radeon Chill monitors the game status in real time, automatically reducing the frame rate when the player does not operate the mouse or keyboard. Once the player's operation is detected, the graphics card will immediately resume the previous high-performance operation. In other words, Radeon Chill's principle is to reduce the number of frames when operating the gap, while maintaining the number of frames in operation, which invisibly reduces the graphics card power consumption without affecting the player's operating experience.

The Radeon Chill feature is set in the AMD driver settings. Players need to click Global Settings - Global WattMan - Chill, turn on the global switch, and then turn on Radeon Chill, as long as the game you play supports this feature. At the beginning of the feature release, a total of 18 games support this feature, but unfortunately Radeon Chill currently only supports DX9 and DX11 games. To use this feature in DX12 games, AMD later upgrades are required.
Supported Rendering Format
  • HDMI 4K Support
  • 4K H264 Decode
  • 4K H264 Encode
  • H265/HEVC Decode
  • H265/HEVC Encode
  • Supported Technologies
  • Radeon Software
  • Radeon FreeSync Technology
  • AMD LiquidVR Technology
  • 4th Gen GCN Architecture
  • Radeon Chill
  • Radeon ReLive
  • DirectX 12 Technology
  • AMD Eyefinity Technology (Gaming)
  • AMD App Acceleration
  • AMD CrossFire Technology
  • AMD CrossFire (Bridgeless)
  • 3rd Gen 14nm Process Technology
  • OpenCL 2.0
  • OpenGL 4.5
  • AMD PowerTune Technology
  • TrueAudio Next
  • Unified Video Decoder (UVD)
  • Video Code Engine (VCE)
  • Virtual Super Resolution
  • The Vulkan API
  • Radeon RX 570,Radeon RX 560,Radeon RX 550 Parameter comparison
    Radeon RX 570Radeon RX 560Radeon RX 550
    ArchitectureGCN 4.0GCN 4.0GCN 4.0
    Transistor Count5.7 billion3.0 billion2.2 billion
    Process Tech14 nm14 nm14 nm
    Die Size232 mm²123 mm²103 mm²
    Next Gen Compute Units32168
    Stream Processors20481024512
    Texture Units1286432
    Base GPU Clock1170 MHz1173 MHz1100 MHz
    Boost GPU Clock1240 MHz1271 MHz1180 MHz
    Memory Clock1.7 Gbps1.7 Gbps1.75 Gbps
    Peak SP Performance5.0 TFLOPS2.6 TFLOPS1.2 TFLOPS
    Memory Size4 GB GDDR54 GB GDDR52 GB GDDR5
    Memory Bus256 bit128 bit128 bit
    Memory Bandwidth225.0 GB/s113 GB/s113 GB/s
    TDP120 W75 W50 W
    Power Connectors6 Pin--
    ROPs321616
    Peak Texture Fill-Rate160 GT/s82.3 GT/s38.6 GT/s
    Peak Pixel Fill-Rate40.2 GP/s22.1 GP/s19.3 GP/s
    GPUPolaris 20Polaris 21Lexa
    Tips: The above parameters are for reference only, and certain parameter values may be in error with the official figures.
    Radeon RX 560 driver installation information
    The following is driver installation information, which is very useful to help you find or install drivers for Radeon RX 560.For example: Hardware ID information item, which contains the hardware manufacturer ID and hardware ID. These two ID values are unique and will not be duplicated with other hardware. According to these two ID values, the matching driver information can be accurately found. This method is more effective than any others, and 100% correct.There are many other information items that you can use to find the driver version information and the required driver files.

    The name of the driver type in the system is: , and the drive type GUID is: .

    Haven't found the right driver yet? Are you facing difficulties in the driver search process?

    1. The drivers you found aren't compatible.

    2. You don't know how to search for drivers.

    3. Your device isn't installed with drivers and appears as an "unknown device" in the system. You don't know how to find drivers for it.

    This website offers a new method for finding drivers, a precise and fast way. Click here to use the new feature.
    Use the search function to find the driver you need

    Many hardware names are usually named after the chip model, and each chip model has its own dedicated driver, so as long as you know the chip model used by the hardware, you can find the right driver. For example, if your graphics card is named: "AMD Radeon RX 580", while actually the core chip model used is: "Radeon RX 580", then enter "Radeon RX 580" or "RX 580" to find the driver.

    If you have a laptop or an all-in-one PC, you can also use the product name to search, and then go to the download page which has all the drivers for this machine (including: graphics card, network card, sound card, etc.). For example, if your laptop product name is: "Dell A6-9220e Inspiron Flagship", then type "Dell A6-9220e" to find all the drivers for this laptop.

    Search steps:

    1. Enter a keyword in the input box and click the "Search" button

    2. In the query results, find the driver file you need, and click the download button

    Driver Finder:

    • Can't find the required driver files?
    • Don't know how to find driver files?
    • Unable to download driver files due to unstable network?
    You can try using this driver file finder. The method of use is very simple. The program will automatically list all the driver files available for your current system. You can install drivers for devices that do not have drivers installed, and you can also upgrade drivers to the latest driver version for devices that have already installed drivers. Click here to download the driver finder.
