AMD Graphics Card Radeon 540X






(3 stars by 88 users)


Radeon 540X is a graphics card from AMD, It has 512 stream processors, 14 nm's process technology makes us admire the strength of AMD, The number of transistors on the GPU is up to 2.2 billion, The GPU running frequency is 1124 MHz. Although the frequency will affect the performance of the graphics card, now, this parameter is not an important parameter, The graphics processor used by the GPU is Lexa, The whole graphics card layout uses GCN 4.0 architecture, Although Radeon 540X video memory is only 4 GB GDDR5, now measuring the performance of a graphics card does not only focus on the memory size, Its 1219 MHz Boost frequency is supposed to balance the heat and performance, 1.2 TFLOPS single-precision floating-point power can process more geometry in a short amount of time, The memory bit width is 64 bit (the number of bits of data that can be transferred in one clock cycle), The memory frequency (1.5 Gbps) parameter is not very important, just for a reference, The number of transistors on the GPU is up to 2.2 billion, The rated power 50 W is generally maintained at around 60% for daily use, Fans who like to watch HD video have a good fortune, as 32 texture processors on the graphics card can process HD video smoothly, Although the chip area is only 103 mm², it can also be inserted into a large number of transistors with the current AMD process technology.

The Radeon 540 uses the Polaris 12 core and has 8 CU units, which are 512 stream processors, as well as 32 textures and 16 raster units. RX 550 basic frequency is 1100MHz, acceleration frequency is 1183MHz, memory is 2 or 4GB GDDR5, equivalent memory frequency is 7000MHz, memory bandwidth is 128bit, and memory bandwidth is 112GB/s.

The Radeon 540 has lower positioning. The memory frequency is 6000MHz, the memory bandwidth is 64Bit, and the memory bandwidth is 48GB/s, but the core acceleration frequency is higher than the RX 550, which is 1219MHz.

Radeon 540 graphics card has an entry level position, but its support features are quite a lot, including DX12, Vulkan, FreeSync, Radeon Chill, and can be qualified for 4K video, and e-sports games like LOL.

Supported Rendering Format
  • HDMI 4K Support
  • 4K H264 Decode
  • 4K H264 Encode
  • H265/HEVC Decode
  • H265/HEVC Encode
  • Supported Technologies
  • Radeon Software
  • Radeon FreeSync Technology
  • 4th Gen GCN Architecture
  • Radeon Chill
  • Radeon ReLive
  • DirectX 12 Technology
  • AMD App Acceleration
  • The Vulkan API
  • Radeon 550X,Radeon 540X,Radeon RX 590 Parameter comparison
    Radeon 550XRadeon 540XRadeon RX 590
    ArchitectureGCN 4.0GCN 4.0GCN 4.0
    Transistor Count2.2 billion2.2 billion5.7 billion
    Process Tech14 nm14 nm12 nm
    Die Size103 mm²103 mm²232 mm²
    Next Gen Compute Units10836
    Stream Processors6405122304
    Texture Units4032144
    Base GPU Clock1100 MHz1124 MHz1470 MHz
    Boost GPU Clock1290 MHz1219 MHz1535 MHz
    Memory Clock1.5 Gbps1.5 Gbps2.0 Gbps
    Peak SP Performance1.6 TFLOPS1.2 TFLOPS7.2 TFLOPS
    Memory Size4 GB GDDR54 GB GDDR58 GB GDDR5
    Memory Bus64 bit64 bit256 bit
    Memory Bandwidth49.0 GB/s47.00 GB/s255.0 GB/s
    TDP50 W50 W175 W
    Power Connectors--8 Pin
    ROPs161632
    Peak Texture Fill-Rate52.8 GT/s40.2 GT/s221.2 GT/s
    Peak Pixel Fill-Rate22.9 GP/s17.0 GP/s50.12 GP/s
    GPULexaLexaPolaris 30
    Tips: The above parameters are for reference only, and certain parameter values may be in error with the official figures.
    Radeon 540X driver installation information
    The following is driver installation information, which is very useful to help you find or install drivers for Radeon 540X.For example: Hardware ID information item, which contains the hardware manufacturer ID and hardware ID. These two ID values are unique and will not be duplicated with other hardware. According to these two ID values, the matching driver information can be accurately found. This method is more effective than any others, and 100% correct.There are many other information items that you can use to find the driver version information and the required driver files.

    The name of the driver type in the system is: , and the drive type GUID is: .

    How to Find Drivers for Unknown Devices in Windows?
    For "unknown device" without driver installed, how to find the correct driver for this type of device? You can find the driver as follows. This is a simple and effective method.<Teach You How To Find Drivers For Unknown Devices In Your System>
    Use the search function at the top to find the driver you need

    Many hardware names are usually named after the chip model, and each chip model has its own dedicated driver, so as long as you know the chip model used by the hardware, you can find the right driver. For example, if your graphics card is named: "AMD Radeon RX 580", while actually the core chip model used is: "Radeon RX 580", then enter "Radeon RX 580" or "RX 580" to find the driver.

    If you have a laptop or an all-in-one PC, you can also use the product name to search, and then go to the download page which has all the drivers for this machine (including: graphics card, network card, sound card, etc.). For example, if your laptop product name is: "Dell A6-9220e Inspiron Flagship", then type "Dell A6-9220e" to find all the drivers for this laptop.

    Search steps:

    1. Enter a keyword in the input box and click the "Search" button

    2. In the query results, find the driver file you need, and click the download button
